KXM-3110D is a 31″ ture 4K HDR Master monitor with dual layer LCD panel which offers 1000 Nits ultra high brightness and 1,000,000:1 contrast ratio. Equipped with 2x12G/6G/3G/HD/SD-SDI inputs and outputs, it is ideal for 4K quality-demanding studio, color grading, and production.

  • 31″ 4096×2160 4K resolution, 10Bit IPS panel
  • 12 Bit Video Processing
  • 1000nits high brightness
  • 3Color space: REC709/EBU/DCI-P3 D65/DCI-P3/REC2020/USER1/USER2/Bypass
  • User 3D LUT file import
  • 4K Mode,Quad-Split Mode,FHD single picture mode
  • 4K 2 Sample Interleave(2SI) and SQD
  • High Dynamic Range(HDR) display
  • HDR supports PQ,HLG
  • Waveform,Vectorscope
  • Audio Level Meter(16CH for SDI,2CH for HDMI)
  • Scan,Markers,Blue Only/Mono Only

$35,999.00

Description



Specification

LCD

Display Size 31″
High Resolution 4096×2160
Aspect Ratio 17:9
Wide Viewing Angle 178°(H) / 178°(V)
Pixel Pitch 0.1704×0.1704(mm)
Color Depth 1.07B(True 10bit)
Back Light LED
Brightness 1000cd/m²
Contrast Ratio 1000000:1



Input

4 × BNC 2x12G-SDI inputs (12G/6G/3G/HD/SD-SDI auto detect),2x3G/HD-SDI inputs
1 × DVI DVI input, compatible with HMDI 2.0 signal

Output

4× BNC 2x 12G-SDI loopout(12G/6G/3G/HD/SD-SDI auto detect),2x3G/HD-SDI outputs



Compatible SDI Format

SMPTE 2082 2160p(60/59.94/50)
SMPTE 2081 2160p(30/29.97/25/24/23.98)
SMPTE-425M-A/B 4:2:2 YCbCr 10-bit 1080p(50/59.94/60)
4:4:4 YCbCr/RGB 10-bit 1080i(60/59.94/50)
4:4:4 YCbCr/RGB 12-bit
1080p(30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
4:2:2 YCbCr 12-bit 1080i(60/59.94/50)
1080p(30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
4:4:4 YCbCr/RGB 10-bit 720p(60/59.94/50/30/29/25/24/23.98)
SMPTE-274M 1080i(60/59.94/50)
1080p(30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
SMPTE-296M 720p(60/59.94/50/30/29/25/24/23.98)
SMPTE-260M 1035i(60/59.94)
SMPTE-125M 480i(59.94)
ITU-R BT.656 576i(50)



Audio In/ Out

SDI Audio In 64CH aduio disembedded/Display any 4 channels
Audio Meter Display Vertical/Horizontal Audio Level Meter Display
Audio Headset Output 3.5mm Headset Jack
Built-in Speaker 2.5W×2



General

Operating Temperature -10℃~50℃
Input Voltage AC 100-240V 50/60Hz
VESA Installation ESA MIS-D(200X200mm)
Shell Materials Aluminum on Front-Shell
Rust-Proof iron on Back-Shell
Accessory Power cord
