  • Modular design for different shooting scenes
  • Arca-Swiss camera quick release design
  • Baseplate with an ARRI-style dovetail
  • One-side locking knob to lock two 15mm rods at the same time
  • A/B hard stop follow focus and universal matte box
  • Power supply system

$1,833.00

Description

The LanParte A6000K-02 Camera Kit includes the A6000K-01 basic camera kit, a follow focus, a matte box, a gear ring, a V-mount battery pinch, a V-mount battery, and a battery pack.

The A6000K-01 camera kit has a top handle that connects to the cage via a standard NATO rail system. It also has 1/4″-20 and 3/8″-16 threads on both sides for mounting accessories. Your camera connects to the cage via an Arca-Swiss quick release plate.

The follow focus clamps onto the cage’s 15mm LWS rods, allowing you to accurately pull focus with cinema and DSLR lenses. The included rubber gear ring has a standard pitch of 0.8 and a maximum diameter of 4.1″. The universal matte box includes one filter holder that supports 4 x 5.65 filters and one rotating filter holder that supports 4 x 4 square filters, as well as 109 to 112mm diameter round filters. Also included are a 95mm lens clamp adapter and adjustable top and side flags.

The Battery Dummy enables the use of the included 150Wh Sony V-mount Li-ion battery to supply power to Sony a7, NEX-5, 5R, 5T, 5TL, a5100, a5000, and a600 cameras. Additionally, the included V-mount battery pinch features multiple power outputs and an integrated HDMI splitter to power your camera.

Specification

󠀡󠀡

Camera Cage
Mounting Points on Top Handle NATO Rail Adapter
Camera Plate Arca-Swiss Quick Release
Rod System Dual 15 mm LWS
Accessory Mounting Top Handle: 1/4″-20 and 3/8″-16 Threads, Cold Shoe
Camera Cage: Multiple 1/4″-20 and 3/8″-16 Threads (Both Sides)
Gear Ring
Pitch 0.8
Maximum Diameter 4.1″ / 10.4 cm
Material Rubber
Matte Box
Filter Stages 2
Filter Size 4 x 5.7″ / 10.2 x 14.5 cm
French Flag Top-, Left-, and Right-Side Flags
Dimensions 11.2 x 3.1 x 7.7″ / 28.5 x 8.0 x 19.5 cm
Weight 2.6 lb / 1.2 kg
Dummy Battery Pack
Compatibility Sony a7R, a7, a33, a35, a37, a55, a7S, a7S II, a7R II, a7 II, a5000, a5100, a6000, a6300, a6500, NEXT-5T, 5R, 3N
Input Voltage Range 7.4 to 8.4 VDC
Cable Connectors Camera Connector: 3.5/1.35 mm Barrel
DC Connector: 5.5/2.1 mm Barrel
Cable Length 12.6″ / 32 cm
Interface Size 0.8 to 2.2″ / 21 to 55 mm
Dimensions 1.2 x 13.8 x 0.8″ / 30 x 350 x 20 mm
Weight 1.4 oz / 40 g
Follow Focus Unit
Pitch Gear 0.8
Rod Compatibility 15 mm Quick Release Clamp
Accessory Port 12 mm ARRI-Standard Accessory Port
Marking Disk Yes
V-Mount Battery Pinch
Output Voltage 5 to 15 VDC
Connectors 5 x DC Jack
1 x D-Tap
1 x USB Type-A
2 x HDMI
Battery Plate Mount Type V-Mount
Accessory Mounting 15 mm LWS Rod Clamp
Sony V-Mount Li-Ion Battery
Mount Type V-Mount
Battery Chemistry Lithium-Ion
Capacity (Wh) 150 Wh
Power Draw 10A
Accessory Port 1 x D-Tap

What's Included

󠀡󠀡

1.LanParte-Fans camera kit(A6000K-01)

2.Universal matte Box (UMB-01)

3.Follow Focus,V2 (FF-02)

4.Gear Ring V2 (FFGR-02)

5.V-Mount Battery Pinch (VBP-01)

6.V-Mount Battery (VB-150)

7.Dummy Dattery Pack (FW-50P)
